Product Details:
|
Product Name: | 180 Led SMD Round Led Modules For 90 Degree Led High Bay Light | Lens Size: | Dia234.9mm X H9.38mm |
---|---|---|---|
PCB Size: | Diameter 204.5mm | Beam Angle: | 90 Degree |
Match Led: | 3030 SMD , OSRAM S5, Lumileds 2D | Material: | Optical Grade PC |
Efficiency: | 91% | PCB Circuit: | 6 Series 30 Parallels |
Led Voltage: | 6 V/W | Heat Sink: | Dia 271 X H114mm |
High Light: | led smd module,Cree LED Module |
Product Name | Model | Beam Angle | Dimension |
180 in 1 lens | SOE-HB180-90 | 90° | Φ235 x H9.38mm |
180 in 1 PCB | SOE-HB180-90 | Φ205 x H1.6mm | |
Gasket | SOE-HB180-90 | Φ217.19 x H3.2mm | |
Heatsink | SOE-HB180-90 | Φ271 x H114mm |
Product combined with Geometric Surface Design,High light efficiency;
On the basic character of 3030 series light, show the application of
the Combination of optical and construction.
180 in 1 Lens Drawing:
PCB Drawing for 180 in 1 Lens:
PCB
LED type: 3030 SMD
LED quantity minimum: 180
LED quantity maximum: 180
Assembled MCPCB: yes
PCB shape: round
PCB size: ø 205 mm
MCPCB thickness: 1,6
PCB material: Aluminium
Distribution:
Heatsink Drawing:
High bay and low bay lighting Application:
Industrial factory,
warehouse,
stadium,
hypermarket,
supermarket
and other indoor environments.
Advantages
1. Top grade waterproof rank : IP65
2. Long lifespan > 50,000 hrs
3. Low voltage, safe for human
4. Green Light, protect for environment
5. Low power consumption , high efficiency
6. Excellent heat output
Led waterproof driver
Optional brands of Led driver, detached design of power supply. The isolating switching power supply, low voltage output, low harmonics, no strobe, high efficiency, ling life-span.
Industry Leading heat dissipation design
Adopt AL6063 aluminum housing, IP65. Simple but original design, which ensures excellent ventilating effect, corrosion and wind resistance.
Unique elegant appearance
A new design concept about a conventional breakthrough in housing, for offering highly integration solving solution.
Excellent Design
Adopt high brightness LEDs, energy saving, no strobes, no radiation, safe and environmental protection, no harm to people. Long life span, up to 50000 hours. Impact and shock resistance, no UV and IR radiation. It is also reliable when working in low voltage.
Using aluminum housing and strong anti-corrosion, waterproof, dust-proof. With oxidation treatment on the surface of the radiator, it is durable and impact-resistant. The integrative structure simplify the spot wiring, it's more easy for installation and maintenance. Sealing parts are made of silicon rubber, which keeps oil-resistant, acid-resisting, alkali-resisting and heat-resistant.
NOTE: The typical divergence will be changed by different color, chip size and chip position tolerance. The typical total divergence is the full angle measured where the luminous intensity is half of the peak value.
