Product Details:
|
| Product Name: | COB Led Glass Lens High Transmittance For 10w-200w Led Industrial Light | Diameter: | 50, 56, 66, 78, 100, 114, 130mm |
|---|---|---|---|
| Height: | 20mm | Beam Angle: | 35, 40, 45, 60, 90, 120 Degree, 65x135, 70x140, 70x160 Degree |
| Match Led: | 10-200W | Material: | Optical Grade High Borosilicate Glass |
| Working Temperature: | -50 To 60 °C | Accessories: | Lens, Gasket , Metal Holder , COB Led |
| Type: | Clear, Anti-Glare | ||
| High Light: | Glass Led lens,led cob lens |
||
Quick Detail:
1. Dimension: 50, 56, 66, 78, 100, 114, 130mm
2. Beam Angle: 35, 40, 45, 60, 90, 120 degree, 65x135, 70x140, 70x160 degree
3. Match Led: 10-200w LEDs
4. Materials : Glass
5. Accessories: Metal holder,silicon gasket
Specifications:
| Product Name | COB Led Glass lens High transmittance for 10w-200w Led Industrial Light |
| Model No | SOE-SL/HB |
| Main parts | Optical glass Lens+silicone gasket+metal holder+Multichip LED+Driver |
| Lens Material | Borosilicate Glass |
| MOQ | 10pcs |
| Delivery | 7-9 days |
| Certificate | ROHS, SGS |
| Quality guarantee | If you receive defective items, please email us a picture of the defective part. We will send you replacement without extra charger, or offer refund. |
| Main market |
Europe, South America,North America, Asia |
Related Glass lens:
| Model No. | Lens angle | Lens Dimensions | Match Led |
|
SOE-SL107-A4 |
160x70° | D107mm*H31mm | 50-200W |
|
SOE-SL107-A3
|
135x65° | D107mm*H32mm | 50-200W |
|
SOE-SL107-A2 |
140x70° | D107mm*H33mm | 50-200W |
|
SOE-SL107-A |
140x70° | D107mm*H32mm | 50-200W |
|
SOE-SL78 |
120x60 | D78mm*30 | 50-200W |
NOTE: The typical divergence will be changed by different color, chip size and chip position tolerance. The typical total divergence is the full angle measured where the luminous intensity is half of the peak value.
Material Details:
Optical Grade High Borosilicate Glass, This material increases light transmittance through the lens compared to plastics and lower-quality glass.
Abbe number : 65
Light transmittance (2mm): 92%
High hardness
Never get yellow comparing with PMMA material
Refractive index : 1.474
Thermal expansivity : (3.3 ± 0.1)×10-6/K
Heat resistant : working at -50~550 °C
Density (20 °C) : 2.23 gcm-1
