Product Details:
|
| Product Name: | 56W LED PC Lens Array Asymmetric For SMD 3528 Led Street Light Modules | Lens Dimension: | L256.6*W78.6*7.1mm |
|---|---|---|---|
| Heat Sink: | L310*W80*H43mm | Beam Angle: | 30x70/60x90/155x80 Degree |
| Match Led: | SMD 3030, S5, Lumileds 2D, 2835 | Material: | Optical Grade PC |
| Working Temperature: | -35℃ +100℃ | PCB Circuit: | 7 Series 8 Parallels |
| Led Driver: | AC 110-2265V | ||
| High Light: | cree led array,multi lens array |
||
1. Dimension: L256*W78*7.1mm
2. Beam Angle: 30x70/60x90/155x80 degree
3. Match Led: SMD 3030 3528
4. Materials : Optical Grade PC, Aluminm
5. Accessories: Led lens, Silicone Gasket, PCB soldeirng Led, Heat Sink, waterproof Cable
6. Efficiency: >91%
Specifications:
| Product Name | 56W LED PC Lens Array Asymmetric for SMD 3528 Led Street Light Modules |
| Model No | SOE-SL56W-30x70/60x90/155x80 |
| Main parts | PC Lens+ Silicone gasket + AL PCB mounting leds |
| Lens Material | PC Optical |
| MOQ | 1 pc |
| Lens size | 256.6x78.6x7.1mm |
| PCB Size | 233x55x1.5mm |
| Driver enclosure | plastic or aluminum case for choice |
| PCB Circuit | 7 series 8 parallel or Request as customer's |
| Certificate | ROHS, SGS,CE |
3030 SMD Led Lens Array Drawing:
Related SMD 3030 Led Street Light Lens:
| Model No. | Lens angle | Lens size(L*W*H) | PCB size(L*W*H) |
|
SOE-SSL56W30F
|
30° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W60F
|
60° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W90F
|
90° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W30x70F
|
30x70° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W60x90F
|
60x90° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W145x70F
|
145x70° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W155x80F
|
155x80°, Asymmetric 35° | 256.6x78.6x7.1mm | 233x55x1.5mm |
|
SOE-SL56W90x90F
|
90x90° | 250x74x8.2mm | 229x53x1.5mm |
|
SOE-SL56W145X75F
|
145X75° | 250x74x8.2mm | 229x53x1.5mm |
Application:
For these 56w led Lens array with IP65 waterproof, it could use for Street light, tunnel Light, High Pole Light, Led garden light and so on.
